Getting started with Galvorn
Everything you need to handle, cut, and terminate Galvorn® from first samples to production, in one place.
Galvorn is a conductor that handles more like a yarn or a fabric than a metal wire, so the first few cuts and terminations can feel unfamiliar. This page collects the guidance DexMat engineers give most often to people working with Galvorn for the first time: what to read before you start, how to cut the material cleanly, and how to make a reliable termination.
New to Galvorn? Start with the intro demo.
What do you need to start working with Galvorn?
A sharp coated blade, a way to hold the material under tension, and the termination method that fits your product form. Galvorn ships as fiber tow, twisted yarn, braided yarn, fabric, and film, and each one is handled a little differently. The Galvorn Guide covers handling, storage, and safety for all five, and the videos below show the two steps people ask about most.
Galvorn® is an advanced carbon material that DexMat supplies as fiber, yarn, fabric, and film, and it can be cut and terminated with tools most facilities already have.
Start here
Start with the data sheet and the guide
Data sheet
Galvorn Data Sheet
Every Galvorn product sold in the samples store, with its properties listed by size. Use it to choose a form and size before you order.
Guide
Galvorn Guide
Best practices for handling Galvorn: unpacking, storage, environmental considerations, safety, and the cutting and termination methods shown on this page.
Handling how-tos
Cutting Galvorn fabric with a coated razor blade on a cutting board.
How to cut Galvorn
Cutting is the first question most new users ask. These methods come from DexMat's own production floor, and the Galvorn Guide covers them in more detail.
- Use a razor blade, ideally coated (titanium nitride or similar) to slow oxidation, and change blades often.
- Cut under tension, or with the material bound by tape, glue, or its insulation.
- Cut against a soft backer, such as a cutting board.
- For precise cuts on film and fabric, laser trimming works where a blade is harder to control.
How to terminate uninsulated Galvorn
Watch a step-by-step demonstration of terminating bare Galvorn, then read the guide for the connectors and settings used.
Crimping a terminal onto uninsulated Galvorn yarn.
Crimping a terminal onto insulated Galvorn.
How to terminate insulated Galvorn
Watch a step-by-step demonstration of terminating insulated Galvorn, then read the guide for the connectors and settings used.
Scaling up
From samples to production
The methods above work at the bench and on the line. When you move to automated wire processing, such as measuring, cutting, stripping, or crimping machines, DexMat tunes the yarn's stiffness with you so it runs cleanly on your equipment. Use crimp tools with adjustable or calibrated dies rather than dies made for a range of copper sizes, and keep any insulation process inside Galvorn's temperature limits, which the Galvorn Guide gives.
Galvorn yarn also knits, weaves, and embroiders on standard textile equipment. DexMat supplies insulated yarn on request and ships lengths from meters to kilometers.
Product forms
Which Galvorn form do you need?
Galvorn is sold in five forms, and the right one depends on what you're building. Each store page lists sizes and properties, and special orders are available for sizes and constructions not in the store.
| Form | Typical starting point | Store |
|---|---|---|
| Galvorn® Fiber Tow | Your own yarn, braid, or composite construction | 1000 Fiber Tow · 800 Fiber Tow |
| Galvorn® Twisted Yarn | Conductors for wire, cable, and stitched circuits | 1000 Twisted Yarn · 800 Twisted Yarn |
| Galvorn® Braided Yarn | Larger-diameter conductors and cores where break force matters | 1000 Braided Yarn |
| Galvorn® Fabric | Textiles and flat conductive layers | Galvorn Fabric |
| Galvorn® F10 Film | Thin shielding and thermal layers | F10 Film |
FAQ
Common questions
No. A coated razor blade, a cutting board, tape to hold the material under tension, and standard crimp tools cover the cutting and termination methods shown on this page. The Galvorn Guide lists what DexMat uses in its own facility.
Still have a question?
Tell us what you're building and where you're stuck. A DexMat engineer will reply.
